LITHTECH 51.2V/200Ah WALL MOUNT RESIDENTIAL ENERGY STORAGE

Factory directly sales, Supports Retail and Wholesale
Fast Charging & Turbo-Boost Technology
Support 1C charging & discharging, with Lithtech Turbo-Boost technology, the system can output 1.25C power for nonlinear load application.
Ultra-Safety
Full range of protection, up to 18 electronic protection in Lithtech smart BMS, plus with aerosol fire extinguishing system(optional).
Intelligent Operation
New intelligent touch screen, support to prevent accidental touches, operate with full information processing, Wi-Fi and Bluetooth dual configuration.
Strong Compatible Ability
Can compatible with most of mainstream inverter brands in the market such as Deye, Growatt, Magarevo, Victron, SRNE etc.
Long Life A Class LFP Battery
Original top brand battery cell, long life, minimum 5 years maintenance free
Certification: CE/UL1973/UN38.3

Electrical Characteristics	Nominal Voltage	51.2Volt
	Nominal Capacity	200Ah
	Energy	10.24Wh
	Internal Resistance	45≤mΩ
	Cycle Life	6000 Cycles
	Months Self Discharge	≤3.5% per month at 25℃
Standard Charge	Charge Voltage	56.8V~57.6V±0.2V
	Charger Current	25A
	Max.Charge Current	50A
Standard Discharge	Discharge Current	50A
	Max. Continuous Current	100A
	Max.Pulse Current	180A(＜3S）
	Disxcharge Cut-off Voltage	35.2V
Environmental	Charge Temperature	0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
	Disxcharge Temperature	-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
	Storage Temperature	0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
	Water Dust Resistance	IP55
Mechanical	Cell & Method	LFP/AL-102AH, 16S2P Prismatic
	Plastic Case	Steel
	Dimension(LWH)	780556219mm
	Weight	Approx.86kg
	Terminal	OEM
